AKS Production Hardening: A 2026 Security and Reliability Checklist


Executive Snapshot

Private Virtual Network«AzureKubernetesService»AKS[Private cluster]«AzureContainerRegistry»Container Registry[Private endpoint]«AzureKeyVault»Key Vault[CSI secrets]«AzureActiveDirectory»Microsoft Entra ID[Workload identity]«AzureSecurityCenter»Defender for Cloud[Containers + Policy]federated tokenpull imagemount secretgovernance + scan
Hardened AKS topology with registry, identity, secrets and Defender governance.
Category Recommendation
Identity & Access Workload Identity + Microsoft Entra ID RBAC; disable local accounts
Network Private cluster + Azure CNI Overlay; enforce Calico or Cilium NetworkPolicy
Node Security CIS-hardened node images; node auto-upgrade on patch channel
Workload Isolation Namespace-scoped RBAC; OPA Gatekeeper or Kyverno admission control
Secrets Azure Key Vault CSI driver; zero plaintext Secrets in etcd
Observability Azure Monitor + Prometheus/Grafana; enable audit logs to Log Analytics
Reliability PodDisruptionBudgets + topology spread; cluster autoscaler + KEDA
Supply Chain Defender for Containers image scanning; signed images via Notation
Backup & DR Velero to Azure Blob; multi-region standby or Azure Backup for AKS
Compliance Azure Policy for Kubernetes; CIS AKS Benchmark v1.5 alignment

TL;DR

flowchart TD
    Start([New AKS cluster]) --> Net{Private cluster?}
    Net -->|No| FixNet[Enable private API server]
    Net -->|Yes| Auth
    FixNet --> Auth
    Auth{Entra workload identity?}
    Auth -->|No| FixAuth[Disable local accounts
enable workload identity] Auth -->|Yes| Sec FixAuth --> Sec Sec{Secrets in Key Vault?} Sec -->|No| FixSec[Mount via CSI driver] Sec -->|Yes| Img FixSec --> Img Img{Images scanned in ACR?} Img -->|No| FixImg[Enable Defender scan
+ admission control] Img -->|Yes| Gov FixImg --> Gov Gov{Azure Policy enforced?} Gov -->|No| FixGov[Apply baseline initiative] Gov -->|Yes| Done FixGov --> Done Done([Hardened cluster]) classDef gate fill:#1f6feb,stroke:#58a6ff,color:#fff; classDef fix fill:#3a2d00,stroke:#d29922,color:#fff; classDef term fill:#238636,stroke:#2ea043,color:#fff; class Net,Auth,Sec,Img,Gov gate; class FixNet,FixAuth,FixSec,FixImg,FixGov fix; class Start,Done term;
Sequential gate-by-gate decision flow to harden a production AKS cluster.
  • AKS production hardening is a multi-layer discipline — perimeter, node, workload, identity, and supply chain each need explicit controls.
  • Workload Identity replaces pod-managed identity and is now the only supported approach for production credential management in 2026.
  • Private clusters with Azure CNI Overlay and Cilium are the recommended network baseline — public API endpoints are a critical risk in production.
  • Admission controllers (Gatekeeper or Kyverno) are non-negotiable for enforcing policy at deploy time; Azure Policy alone is insufficient for runtime.
  • Reliability is part of hardening — misconfigured PDBs and missing topology spread constraints are among the top causes of avoidable production incidents.

Introduction

Running a Kubernetes cluster on Azure is straightforward. Running one in production that survives real-world adversaries, noisy-neighbour workloads, upstream CVEs, and 3 a.m. node pool drain events — that's the hard part.

Azure Kubernetes Service has matured significantly, but the platform's flexibility means it ships with several defaults that prioritise ease of onboarding over security depth. Local admin accounts are enabled by default. The API server is public unless you explicitly opt out. Node pools don't auto-upgrade unless you configure the channel. None of these are accidents — they're trade-offs that make sense for a first cluster but are liabilities in production.

This checklist consolidates the 2026 AKS security and reliability baseline: updated for Kubernetes 1.30+, the GA of Cilium as an AKS CNI option, the deprecation of AAD Pod Identity in favour of Workload Identity, and the General Availability of Azure Backup for AKS. Each section is actionable, with tested commands you can run today. Work through it sequentially or jump to the layer most relevant to your current risk posture.


Prerequisites

  • An existing AKS cluster or permission to create one (Contributor + User Access Administrator on the subscription)
  • Azure CLI ≥ 2.61 (az --version) with aks-preview extension installed
  • kubectl ≥ 1.30 configured with cluster admin context for initial setup
  • Helm ≥ 3.14 for add-on deployments
  • Familiarity with Kubernetes RBAC, NetworkPolicy, and basic Azure IAM concepts
  • (Recommended) Terraform or Bicep IaC pipeline — hardening is most durable when codified

Architecture: AKS Hardening Layers

flowchart TD
    subgraph External["External / Internet"]
        User["Developer / CI Pipeline"]
        Attacker["Threat Actor"]
    end

    subgraph Azure["Azure Subscription Boundary"]
        subgraph Network["Private VNet"]
            AGW["Azure Application Gateway\n(WAF v2)"]
            APIGW["API Server\n(Private Endpoint)"]

            subgraph AKS["AKS Private Cluster"]
                subgraph CP["Control Plane (Microsoft-managed)"]
                    etcd["etcd\n(encrypted at rest)"]
                    APIServer["kube-apiserver"]
                end

                subgraph NP1["System Node Pool\n(CIS-hardened)"]
                    Gatekeeper["OPA Gatekeeper\nAdmission Webhook"]
                    CSI["Key Vault CSI\nDriver"]
                end

                subgraph NP2["User Node Pool\n(Spot / On-demand)"]
                    Pod1["Workload Pod\n(Workload Identity)"]
                    Pod2["Workload Pod\n(Workload Identity)"]
                end

                NetPol["Calico / Cilium\nNetworkPolicy"]
            end

            KV["Azure Key Vault"]
            ACR["Azure Container Registry\n(Defender scanning)"]
            LA["Log Analytics\nWorkspace"]
        end

        Entra["Microsoft Entra ID\n(RBAC + Workload Identity)"]
    end

    User -->|HTTPS| AGW
    Attacker -->|Blocked by private EP| APIGW
    AGW --> Pod1
    User -->|kubectl via private EP| APIGW
    APIGW --> APIServer
    APIServer --> etcd
    APIServer --> Gatekeeper
    Pod1 -->|OIDC token| Entra
    Entra --> KV
    CSI --> KV
    Pod1 -.->|NetworkPolicy enforced| Pod2
    NetPol -.->|deny-all default| NP2
    APIServer -->|audit logs| LA
    ACR -->|signed + scanned image| NP2

1. Cluster Provisioning: Get the Baseline Right

Hardening retrofitted onto a running cluster is always harder than hardening baked into provisioning. Use this Bicep/CLI baseline.

1.1 Create a Private Cluster with Azure CNI Overlay and Cilium

# Set variables
RG="rg-aks-prod"
CLUSTER="aks-prod-01"
LOCATION="australiaeast"
VNET="vnet-prod"
SUBNET="snet-aks-nodes"

# Create resource group
az group create --name $RG --location $LOCATION

# Create the cluster with production-baseline flags
az aks create \
  --resource-group $RG \
  --name $CLUSTER \
  --location $LOCATION \
  --kubernetes-version 1.30 \
  --enable-private-cluster \
  --private-dns-zone system \
  --network-plugin azure \
  --network-plugin-mode overlay \
  --network-dataplane cilium \
  --network-policy cilium \
  --enable-oidc-issuer \
  --enable-workload-identity \
  --enable-azure-rbac \
  --disable-local-accounts \
  --enable-managed-identity \
  --enable-defender \
  --enable-azure-monitor-metrics \
  --enable-addons monitoring \
  --workspace-resource-id "/subscriptions/<SUB>/resourceGroups/$RG/providers/Microsoft.OperationalInsights/workspaces/law-prod" \
  --auto-upgrade-channel patch \
  --node-os-upgrade-channel NodeImage \
  --tier standard \
  --zones 1 2 3 \
  --node-count 3 \
  --node-vm-size Standard_D4ds_v5 \
  --vnet-subnet-id "/subscriptions/<SUB>/resourceGroups/$RG/providers/Microsoft.Network/virtualNetworks/$VNET/subnets/$SUBNET" \
  --generate-ssh-keys

Key flags explained:

Flag Why it matters
--enable-private-cluster API server unreachable from public internet
--network-dataplane cilium eBPF dataplane, Cilium NetworkPolicy, observability
--enable-azure-rbac Kubernetes RBAC backed by Entra ID groups
--disable-local-accounts Eliminates clusterUser/clusterAdmin credential sprawl
--enable-workload-identity OIDC federation for pod-level Azure auth without secrets
--enable-defender Defender for Containers runtime threat detection
--auto-upgrade-channel patch Automated patch-version upgrades
--zones 1 2 3 Control plane + nodes spread across availability zones

2. Identity and Access Control

2.1 Disable Local Accounts on Existing Clusters

If you inherited a cluster that wasn't created with --disable-local-accounts:

az aks update \
  --resource-group $RG \
  --name $CLUSTER \
  --disable-local-accounts

Verify with:

az aks show --resource-group $RG --name $CLUSTER \
  --query "disableLocalAccounts" -o tsv
# Expected output: true

2.2 Configure Workload Identity for Applications

Workload Identity replaces the deprecated AAD Pod Identity. It uses Kubernetes ServiceAccount OIDC federation — no secrets in pods, no credential rotation.

# Step 1: Create a managed identity for the workload
az identity create \
  --name "id-myapp-prod" \
  --resource-group $RG

CLIENT_ID=$(az identity show -n id-myapp-prod -g $RG --query clientId -o tsv)
OBJECT_ID=$(az identity show -n id-myapp-prod -g $RG --query principalId -o tsv)

# Step 2: Get the OIDC issuer URL
OIDC_ISSUER=$(az aks show -n $CLUSTER -g $RG \
  --query "oidcIssuerProfile.issuerUrl" -o tsv)

# Step 3: Create the federated credential
az identity federated-credential create \
  --name "fc-myapp-prod" \
  --identity-name "id-myapp-prod" \
  --resource-group $RG \
  --issuer $OIDC_ISSUER \
  --subject "system:serviceaccount:myapp:myapp-sa" \
  --audiences "api://AzureADTokenExchange"

# Step 4: Grant the identity access (e.g., Key Vault Secrets User)
KV_ID=$(az keyvault show -n kv-prod-01 -g $RG --query id -o tsv)
az role assignment create \
  --role "Key Vault Secrets User" \
  --assignee $OBJECT_ID \
  --scope $KV_ID
# serviceaccount.yaml — annotate with client ID
apiVersion: v1
kind: ServiceAccount
metadata:
  name: myapp-sa
  namespace: myapp
  annotations:
    azure.workload.identity/client-id: "<CLIENT_ID_FROM_ABOVE>"
---
# deployment.yaml — label pods to pick up the token volume
apiVersion: apps/v1
kind: Deployment
metadata:
  name: myapp
  namespace: myapp
spec:
  template:
    metadata:
      labels:
        azure.workload.identity/use: "true"
    spec:
      serviceAccountName: myapp-sa
      containers:
        - name: myapp
          image: myacr.azurecr.io/myapp:1.0.0
          # No environment variables containing secrets.
          # The OIDC token is mounted automatically at
          # /var/run/secrets/azure/tokens/azure-identity-token

2.3 Namespace-Scoped RBAC

Never grant cluster-admin to application teams. Use namespace-scoped roles:

# rbac-dev-team.yaml
apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
  name: dev-team-role
  namespace: myapp
rules:
  - apiGroups: ["apps"]
    resources: ["deployments", "replicasets"]
    verbs: ["get", "list", "watch", "create", "update", "patch"]
  - apiGroups: [""]
    resources: ["pods", "pods/log", "services", "configmaps"]
    verbs: ["get", "list", "watch"]
  # Explicitly deny secrets — teams use Key Vault CSI, not raw secrets
---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: dev-team-binding
  namespace: myapp
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: Role
  name: dev-team-role
subjects:
  - kind: Group
    apiGroup: rbac.authorization.k8s.io
    name: "<ENTRA_GROUP_OBJECT_ID>"

3. Network Security

3.1 Default-Deny NetworkPolicy

The single most impactful network control is a default-deny policy applied to every namespace. Without it, every pod can reach every other pod.

# default-deny-all.yaml — apply to every application namespace
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: default-deny-all
  namespace: myapp
spec:
  podSelector: {}        # Matches all pods in the namespace
  policyTypes:
    - Ingress
    - Egress
---
# Allow specific ingress from ingress controller namespace only
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: allow-ingress-controller
  namespace: myapp
spec:
  podSelector:
    matchLabels:
      app: myapp
  policyTypes:
    - Ingress
  ingress:
    - from:
        - namespaceSelector:
            matchLabels:
              kubernetes.io/metadata.name: ingress-nginx
      ports:
        - protocol: TCP
          port: 8080
---
# Allow egress to Key Vault and Azure Monitor endpoints only
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: allow-egress-azure-services
  namespace: myapp
spec:
  podSelector:
    matchLabels:
      app: myapp
  policyTypes:
    - Egress
  egress:
    - ports:
        - protocol: TCP
          port: 443   # HTTPS to Azure services via private endpoints
    - ports:
        - protocol: UDP
          port: 53    # DNS

3.2 Restrict API Server Authorised IP Ranges (Public Clusters Only)

If you're running a public cluster for any reason (not recommended), at minimum lock the API server:

az aks update \
  --resource-group $RG \
  --name $CLUSTER \
  --api-server-authorized-ip-ranges "203.0.113.10/32,198.51.100.0/24"

4. Admission Control and Policy Enforcement

4.1 Deploy OPA Gatekeeper

helm repo add gatekeeper https://open-policy-agent.github.io/gatekeeper/charts
helm repo update

helm install gatekeeper gatekeeper/gatekeeper \
  --namespace gatekeeper-system \
  --create-namespace \
  --set replicas=3 \
  --set auditInterval=60 \
  --set logLevel=WARNING \
  --set metricsBackends="{prometheus}" \
  --version 3.17.0

4.2 Enforce Critical Constraints

The following ConstraintTemplate blocks privileged containers — one of the most commonly exploited misconfigurations:

# constraint-no-privileged.yaml
apiVersion: templates.gatekeeper.sh/v1
kind: ConstraintTemplate
metadata:
  name: k8snooprivilegedcontainers
spec:
  crd:
    spec:
      names:
        kind: K8sNoprivilegedContainers
  targets:
    - target: admission.k8s.gatekeeper.sh
      rego: |
        package k8snoprivilegedcontainers

        violation[{"msg": msg}] {
          container := input.review.object.spec.containers[_]
          container.securityContext.privileged == true
          msg := sprintf("Container '%v' must not run as privileged.", [container.name])
        }

        violation[{"msg": msg}] {
          container := input.review.object.spec.initContainers[_]
          container.securityContext.privileged == true
          msg := sprintf("Init container '%v' must not run as privileged.", [container.name])
        }
---
apiVersion: constraints.gatekeeper.sh/v1beta1
kind: K8sNoprivilegedContainers
metadata:
  name: no-privileged-containers
spec:
  match:
    kinds:
      - apiGroups: [""]
        kinds: ["Pod"]
    excludedNamespaces:
      - kube-system
      - gatekeeper-system

4.3 Enforce Pod Security Standards via Azure Policy

# Apply the AKS CIS benchmark initiative
az policy assignment create \
  --name "aks-cis-benchmark" \
  --display-name "AKS CIS Benchmark v1.5" \
  --policy-set-definition "c047ea8e-9c78-49b2-958b-37e56d291a44" \
  --scope "/subscriptions/<SUB>/resourceGroups/$RG" \
  --enforcement-mode Default \
  --mi-system-assigned \
  --location $LOCATION

5. Secrets Management

5.1 Mount Key Vault Secrets via CSI Driver

Never use Kubernetes Secret objects for sensitive material in production. The Key Vault CSI driver mounts secrets directly into pods without touching etcd.

# Enable the CSI driver (if not already enabled at cluster creation)
az aks enable-addons \
  --resource-group $RG \
  --name $CLUSTER \
  --addons azure-keyvault-secrets-provider

# Enable secret rotation (default rotation poll: 2 minutes)
az aks addon update \
  --resource-group $RG \
  --name $CLUSTER \
  --addon azure-keyvault-secrets-provider \
  --enable-secret-rotation \
  --rotation-poll-interval 2m
# secretproviderclass.yaml
apiVersion: secrets-store.csi.x-k8s.io/v1
kind: SecretProviderClass
metadata:
  name: myapp-keyvault-secrets
  namespace: myapp
spec:
  provider: azure
  parameters:
    usePodIdentity: "false"
    clientID: "<MANAGED_IDENTITY_CLIENT_ID>"
    keyvaultName: "kv-prod-01"
    tenantId: "<TENANT_ID>"
    objects: |
      array:
        - |
          objectName: db-connection-string
          objectType: secret
          objectVersion: ""
        - |
          objectName: api-key
          objectType: secret
          objectVersion: ""
  secretObjects:                         # Optional: also sync to K8s Secret
    - secretName: myapp-secrets
      type: Opaque
      data:
        - objectName: db-connection-string
          key: DATABASE_URL
---
# Reference in your deployment
apiVersion: apps/v1
kind: Deployment
metadata:
  name: myapp
  namespace: myapp
spec:
  template:
    spec:
      serviceAccountName: myapp-sa
      containers:
        - name: myapp
          image: myacr.azurecr.io/myapp:1.0.0
          volumeMounts:
            - name: secrets-store
              mountPath: "/mnt/secrets"
              readOnly: true
      volumes:
        - name: secrets-store
          csi:
            driver: secrets-store.csi.k8s.io
            readOnly: true
            volumeAttributes:
              secretProviderClass: "myapp-keyvault-secrets"

6. Container Image Supply Chain

6.1 Restrict to Signed Images from Trusted Registries

# Enable image integrity (Notation-based signing verification) on AKS
az aks update \
  --resource-group $RG \
  --name $CLUSTER \
  --enable-image-integrity

# Create an Azure Policy assignment that denies unsigned images
az policy assignment create \
  --name "require-signed-images" \
  --policy "951b3557-235d-4ba4-8e16-803ab58c6176" \
  --scope "/subscriptions/<SUB>/resourceGroups/$RG" \
  --enforcement-mode Default

6.2 Lock Node Pools to a Private ACR

# Attach ACR at cluster level (grants AcrPull to kubelet identity)
az aks update \
  --resource-group $RG \
  --name $CLUSTER \
  --attach-acr "myacr"

# Disable public network access on the registry
az acr update \
  --name myacr \
  --public-network-enabled false

# Enforce via Gatekeeper: only allow images from myacr.azurecr.io
# constraint-allowed-registries.yaml
apiVersion: templates.gatekeeper.sh/v1
kind: ConstraintTemplate
metadata:
  name: k8sallowedrepos
spec:
  crd:
    spec:
      names:
        kind: K8sAllowedRepos
      validation:
        openAPIV3Schema:
          properties:
            repos:
              type: array
              items:
                type: string
  targets:
    - target: admission.k8s.gatekeeper.sh
      rego: |
        package k8sallowedrepos

        violation[{"msg": msg}] {
          container := input.review.object.spec.containers[_]
          not strings.any_prefix_match(container.image, input.parameters.repos)
          msg := sprintf("Container image '%v' is not from an allowed registry.", [container.image])
        }
---
apiVersion: constraints.gatekeeper.sh/v1beta1
kind: K8sAllowedRepos
metadata:
  name: prod-allowed-repos
spec:
  match:
    kinds:
      - apiGroups: [""]
        kinds: ["Pod"]
    excludedNamespaces: ["kube-system", "gatekeeper-system"]
  parameters:
    repos:
      - "myacr.azurecr.io/"

7. Node Security

7.1 Configure Node Auto-Upgrade and Maintenance Windows

# Set a maintenance window to control when auto-upgrades apply
az aks maintenanceconfiguration add \
  --resource-group $RG \
  --cluster-name $CLUSTER \
  --name "aksManagedAutoUpgradeSchedule" \
  --schedule-type Weekly \
  --day-of-week Sunday \
  --start-time "02:00" \
  --utc-offset "+10:00" \
  --duration 4

# Confirm upgrade channels
az aks show -n $CLUSTER -g $RG \
  --query "{upgradeChannel:autoUpgradeProfile.upgradeChannel, nodeOSUpgradeChannel:autoUpgradeProfile.nodeOSUpgradeChannel}" \
  -o table

7.2 Apply Node Taints and Labels for Workload Isolation

# Add a dedicated node pool for sensitive workloads
az aks nodepool add \
  --resource-group $RG \
  --cluster-name $CLUSTER \
  --name sensitivepool \
  --node-count 2 \
  --node-vm-size Standard_D4ds_v5 \
  --node-taints "workload-class=sensitive:NoSchedule" \
  --labels "workload-class=sensitive" \
  --zones 1 2 3 \
  --enable-encryption-at-host \
  --mode User

7.3 Enable Host Encryption and Confidential Computing

# Verify the feature is registered
az feature show \
  --namespace Microsoft.Compute \
  --name EncryptionAtHost \
  --query "properties.state" -o tsv
# Must show: Registered

# Add a confidential node pool (DCdsv3 for AMD SEV-SNP)
az aks nodepool add \
  --resource-group $RG \
  --cluster-name $CLUSTER \
  --name confidentalpool \
  --node-count 2 \
  --node-vm-size Standard_DC4ds_v3 \
  --enable-encryption-at-host \
  --mode User

8. Reliability Patterns

Security and reliability are two sides of the same production-readiness coin. A cluster that crashes under load or drops pods during upgrades fails the availability pillar of your SLA — and availability failures create their own attack surface.

8.1 PodDisruptionBudgets for Every Critical Deployment

# pdb-myapp.yaml
apiVersion: policy/v1
kind: PodDisruptionBudget
metadata:
  name: myapp-pdb
  namespace: myapp
spec:
  minAvailable: "60%"    # At least 60% of pods must stay up during voluntary disruptions
  selector:
    matchLabels:
      app: myapp

8.2 Topology Spread Constraints

# topology-spread in deployment spec
spec:
  template:
    spec:
      topologySpreadConstraints:
        - maxSkew: 1
          topologyKey: topology.kubernetes.io/zone
          whenUnsatisfiable: DoNotSchedule
          labelSelector:
            matchLabels:
              app: myapp
        - maxSkew: 1
          topologyKey: kubernetes.io/hostname
          whenUnsatisfiable: DoNotSchedule
          labelSelector:
            matchLabels:
              app: myapp

8.3 Cluster Autoscaler and KEDA

# Enable cluster autoscaler on the user node pool
az aks nodepool update \
  --resource-group $RG \
  --cluster-name $CLUSTER \
  --name userpool \
  --enable-cluster-autoscaler \
  --min-count 2 \
  --max-count 20

# Deploy KEDA for event-driven autoscaling
helm repo add kedacore https://kedacore.github.io/charts
helm install keda kedacore/keda \
  --namespace keda \
  --create-namespace \
  --version 2.14.0 \
  --set prometheus.metricServer.enabled=true

8.4 Resource Requests, Limits, and LimitRanges

# limitrange-myapp.yaml — enforce sensible defaults and ceilings
apiVersion: v1
kind: LimitRange
metadata:
  name: myapp-limitrange
  namespace: myapp
spec:
  limits:
    - type: Container
      default:
        cpu: "500m"
        memory: "512Mi"
      defaultRequest:
        cpu: "100m"
        memory: "128Mi"
      max:
        cpu: "4"
        memory: "8Gi"
    - type: PersistentVolumeClaim
      max:
        storage: "50Gi"

9. Observability and Audit Logging

9.1 Enable and Retain Audit Logs

# Verify diagnostic settings are sending audit logs to Log Analytics
az monitor diagnostic-settings create \
  --name "aks-diag-prod" \
  --resource "/subscriptions/<SUB>/resourceGroups/$RG/providers/Microsoft.ContainerService/managedClusters/$CLUSTER" \
  --workspace "/subscriptions/<SUB>/resourceGroups/$RG/providers/Microsoft.OperationalInsights/workspaces/law-prod" \
  --logs '[
    {"category":"kube-audit","enabled":true,"retentionPolicy":{"days":90,"enabled":true}},
    {"category":"kube-audit-admin","enabled":true,"retentionPolicy":{"days":90,"enabled":true}},
    {"category":"kube-apiserver","enabled":true,"retentionPolicy":{"days":30,"enabled":true}},
    {"category":"kube-controller-manager","enabled":true,"retentionPolicy":{"days":30,"enabled":true}},
    {"category":"guard","enabled":true,"retentionPolicy":{"days":90,"enabled":true}}
  ]'

9.2 Key KQL Queries for Security Monitoring

// Detect exec into pods (potential container breakout indicator)
AzureDiagnostics
| where Category == "kube-audit"
| extend auditLog = parse_json(log_s)
| where auditLog.verb == "create"
  and auditLog.objectRef.resource == "pods"
  and auditLog.objectRef.subresource == "exec"
| project TimeGenerated,
    User = tostring(auditLog.user.username),
    Namespace = tostring(auditLog.objectRef.namespace),
    PodName = tostring(auditLog.objectRef.name),
    SourceIP = tostring(auditLog.sourceIPs[0])
| order by TimeGenerated desc

// Detect ClusterRole or ClusterRoleBinding creation (privilege escalation)
AzureDiagnostics
| where Category == "kube-audit"
| extend auditLog = parse_json(log_s)
| where auditLog.verb in ("create","update","patch")
  and auditLog.objectRef.resource in ("clusterroles","clusterrolebindings")
| project TimeGenerated,
    Actor = tostring(auditLog.user.username),
    Resource = tostring(auditLog.objectRef.resource),
    ResourceName = tostring(auditLog.objectRef.name)
| order by TimeGenerated desc

10. Backup and Disaster Recovery

10.1 Azure Backup for AKS (GA 2025)

# Register the provider
az provider register --namespace Microsoft.DataProtection

# Create a Backup Vault
az dataprotection backup-vault create \
  --resource-group $RG \
  --vault-name "bv-aks-prod" \
  --location $LOCATION \
  --type SystemAssigned \
  --storage-settings "[{datastore-type:'VaultStore',type:'LocallyRedundant'}]"

# Create a backup policy (daily, 30-day retention)
az dataprotection backup-policy create \
  --resource-group $RG \
  --vault-name "bv-aks-prod" \
  --name "aks-daily-30d" \
  --policy @aks-backup-policy.json

Wrap-up. With backups and the controls above in place, treat this list as a living baseline: re-audit every item each release cycle and validate a restore on a non-production cluster before you depend on it.

Thorsteinn Halldorsson Senior Cloud Engineer

Senior Cloud Engineer with 25+ years of hands-on experience across the datacenter-to-cloud stack: fiber SAN and disk storage, IBM/Lenovo blade and Dell/HP/Lenovo servers, Hyper-V and VMware clusters, and SQL and Remote Desktop Services (RDS) clusters. Deep in the Microsoft platform — Active Directory, PKI/certificate services, SQL, Power BI, Dynamics 365 Business Central (NAV) and AX (Axapta), Microsoft 365, Entra, and Intune — with a focus on Azure operations, FinOps, and applying AI tools like GitHub Copilot and Claude in real workflows. Writes practical, no-nonsense guides for IT professionals who need to ship real solutions.

Leave a Reply

Your email address will not be published. Required fields are marked *
